5006 (SINGLE ROW) SERIES 1.27MM PITCH FMALE HEADER

MATERIAL:
INSULATOR : PBT + 30% GLASS FIBER,
                     UL 94V-0 RATED.
CONTACT : PHOSPHOR BRONZE OR BRASS.
                  (STANDARD IS BRASS)

ELECTRICAL CHARACTERISTICS:
CURRENT RATING : 1 AMP.
WITHSTANDING VOLTAGE : AC 750V R.M.S.
INSULATOR RESISTANCE : 5000 MEGOHMS MIN.
CONTACT RESISTANCE : 20 MILLIOHMS MAX.
OPERATING TEMPERATURE : -55°C ~ +105°C
